Product Overview

Enterprise-grade U.2 / E1.S / E3.S form-factor NVMe solid state drive delivering extremely high IOPS, sub-millisecond latency and enterprise-class reliability. Integrated with Power-Loss Protection (PLP) and end-to-end data path protection, the drives are purpose-built for Oracle databases, OLTP, HPC scratch storage, AI checkpoint storage and all-flash arrays. Read-intensive, mixed-use and write-intensive SKUs are available from 1.92TB up to 30.72TB.

Key Parameters

• Capacity: 3.84TB (1.92TB / 7.68TB / 15.36TB / 30.72TB also available)
• Interface: PCIe 4.0 x4 NVMe 2.0 (PCIe 5.0 optional)
• Form Factor: U.2 2.5" 15mm / E1.S / E3.S / HHHL AIC
• Random Read / Write: Up to 1,500K / 260K IOPS
• Sequential Read / Write: Up to 7,000 / 4,300 MB/s
• DWPD: 1 DWPD mixed use (3 DWPD write-intensive variants)
• Protection: PLP capacitor, end-to-end CRC, RAID engine

Use Cases

• Oracle database online redo logs, temp tables and high-speed tablespaces
• OLTP and all-flash storage arrays (vSAN / Ceph / PowerMax)
• AI training checkpoint storage and HPC scratch buffers
• Database acceleration and in-memory column-store persistence

Warranty

Brand-new enterprise NVMe SSDs with original vendor 5-year warranty. Also offering used/tested drives with our 1-year warranty and professional data-wipe services.
