Oracle Server X6‑4

Oracle Server X6‑4 is a 3U rack‑mounted high‑end enterprise‑class x86 server, purpose‑built for memory‑intensive mission‑critical workloads, including large Oracle database deployment, in‑memory analytics, data warehouse OLAP, and heavy enterprise application consolidation.

The platform supports two or four Intel® Xeon® E7‑8800 v4 series processors with a maximum of 24 cores per socket. It is equipped with 96 DDR4 DIMM slots supporting maximum system memory up to 6 TB, which is critical for running large in‑memory database workloads. The front chassis accommodates six hot‑swap 2.5‑inch drive bays supporting SAS‑3 HDD, SATA‑SSD and high‑performance NVMe‑SSD storage. It provides eleven PCI‑Express Gen‑3 expansion slots for fibre‑channel HBAs, high‑speed 10GbE / 25GbE network adapters and flash accelerator cards to satisfy demanding I/O requirements.

Redundant hot‑swappable power supplies and fan modules reduce the risk of unplanned hardware downtime. The embedded Oracle ILOM service processor delivers comprehensive out‑of‑band remote infrastructure management, real‑time hardware health monitoring, fault alerting and firmware upgrades. Supported operating systems include Oracle Linux, Red Hat Enterprise Linux, SUSE Linux Enterprise Server and Microsoft Windows Server. Oracle Server X6‑4 serves as a high‑performance, robust foundational building block for large‑scale on‑premises data warehouse and memory‑intensive database environments.

Key hardware bullet points

• Form Factor: 3U Rack‑mount

• CPU: 2‑4 × Intel Xeon E7‑8800 v4, max 24 cores per socket

• Memory: 96 DDR4 DIMM slots, maximum up to 6 TB

• Local Storage: Up to 6 × hot‑swap 2.5‑inch bays (SAS‑3 HDD / SATA‑SSD / NVMe‑SSD)

• Expansion: 11 × PCIe Gen3 expansion slots

• System Management: Oracle ILOM service processor

• Redundancy: Hot‑swap redundant power supplies & fan modules

• Supported OS: Oracle Linux, RHEL, SUSE Linux Enterprise Server, Microsoft Windows Server
