Oracle Database Appliance X6‑2‑M

Oracle Database Appliance X6‑2‑M is a 1U rack‑mounted single‑node engineered system purpose‑built for Oracle database workloads. It tightly integrates compute resources, high‑speed NVMe flash storage, networking components and purpose‑optimized appliance software stack, eliminating manual integration of discrete server and storage hardware.

The platform is equipped with two Intel® Xeon® E5‑2630 v4 (10‑core, 2.2 GHz) processors, supporting Oracle’s unique on‑demand core licensing model; customers can activate only a subset of physical processor cores to align database software licensing with actual business requirements. The system ships with 256 GB DDR4‑2400 memory, expandable to a maximum of 768 GB. For local flash storage, it starts with two NVMe SSD drives delivering 6.4 TB raw flash capacity and can be expanded up to four NVMe SSDs for 12.8 TB raw flash. Network interfaces include dual 10GbE SFP+ fiber ports and four 10GBase‑T copper ports for database client connectivity and backup networks.

Hardware monitoring and remote administration are delivered via the embedded Oracle ILOM service processor. The ODA software stack automates system provisioning, Oracle ASM storage management, database deployment, patching and firmware updates. It supports both Oracle Database Enterprise Edition and Standard Edition 2. Suited for mid‑size OLTP workloads, departmental databases and database consolidation projects, the ODA X6‑2‑M provides a simplified, validated database infrastructure solution for on‑premises data centers.

Key hardware bullet points

• Form Factor: 1U Rack‑mount, Single‑node Engineered System

• CPU: Dual Intel Xeon E5‑2630 v4 @2.2 GHz (10‑core each), support on‑demand core licensing

• Memory: 256 GB initial, expandable up to 768 GB DDR4‑2400

• Local Flash Storage: 2 × NVMe SSD (6.4 TB raw), expandable to 4 × NVMe SSD (12.8 TB raw)

• Network: 2 ×10GbE SFP+ (Fiber); 4 ×10GBase‑T (Copper)

• System Management: Oracle ILOM + ODA appliance management software stack

• Supported Database: Oracle Database Enterprise Edition / Standard Edition 2

• Deployment: Single‑node appliance for mid‑tier OLTP, department database consolidation
