Oracle SPARC T5‑4 Server

The SPARC T5‑4 is a 5U rack‑mount SMP enterprise server within the T5 family. It can be configured with either two or four SPARC T5 processors running at 3.6 GHz. Each SPARC T5 CPU provides 16 cores and 128 hardware threads. At the fully populated 4‑socket configuration, the system reaches 64 cores and 512 hardware threads, sitting between the dual‑socket T5‑2 and the high‑end 8‑socket T5‑8 platformOracle.

Each T5 processor embeds dedicated on‑chip crypto accelerators to offload SSL, TLS and database encryption workloads. Please note that the T5 generation does NOT implement Software‑in‑Silicon, Silicon Secured Memory or DAX analytics accelerators – those security‑acceleration features arrived later on the M7 / S7 / T7 product line.

The server supports Oracle VM Server for SPARC (Logical Domains), enabling administrators to partition the large physical server into multiple independent virtual domains for consolidating databases and middleware workloads. Enterprise‑grade RAS features include memory ECC, DIMM sparing, hot‑swap redundant power supplies and redundant fan modules for fault tolerance.

Hardware specifications:

• Form factor: 5‑U rack‑mount chassis

• Processors: 2 or 4 × SPARC T5 @3.6 GHz (16‑core /128‑threads per socket; max 64‑cores /512‑threads)

• Memory: 64 × DDR3 DIMM slots, maximum 2 TB total system memory

• Storage: 8 × front‑loading 2.5‑inch SFF hot‑swap SAS‑2 drive bays; optional DVD‑RW

• Expansion: 16 × hot‑pluggable PCI‑E Gen3 low‑profile slots

• Network: Four onboard 10GBase‑T 10‑Gigabit Ethernet ports

• Management: Oracle ILOM service‑processor for remote lights‑out administration

• Redundancy: Hot‑swap redundant AC power supplies, redundant fan modules, memory sparing

• Supported OS: Oracle Solaris 10, Oracle Solaris 11; Oracle VM Server for SPARC

Typical deployment scenarios include mid‑to‑large OLTP database instances, multi‑tier enterprise application consolidation and department‑level private‑cloud deployments on SPARC Solaris.

Key specification bullet points

• Chassis: 5U Rack‑mount Enterprise Server

• CPU: Scalable 2‑socket /4‑socket SPARC T5 @3.6 GHz (max 64‑Cores /512‑Threads)

• Technology: On‑chip crypto acceleration; No Silicon‑Secured‑Memory / DAX

• I/O: 16 × hot‑pluggable PCI‑E Gen3 low‑profile slots

• Internal Storage: 8 × 2.5” SFF SAS‑2 hot‑swap drive bays

• System Management: Oracle ILOM

• OS Support: Oracle Solaris 10 /11, Oracle VM Server for SPARC

• Enterprise RAS: Memory sparing, redundant hot‑swap PSU & cooling
