Oracle Server X6‑2

Oracle Server X6‑2 is a 1U dual‑socket enterprise‑grade rack‑mount x86 server, designed to run mission‑critical enterprise workloads including Oracle Database and Oracle Real Application Clusters (RAC). Powered by up to two Intel® Xeon® E5‑2600 v4 series processors with a maximum of 22 cores per socket, the system is equipped with 24 DDR4‑2400 DIMM slots supporting up to 768 GB of main memory. The chassis accommodates up to eight 2.5‑inch hot‑swap drive bays for SAS‑3 HDD or SATA‑SSD storage. It provides four low‑profile PCI‑Express Gen‑3 expansion slots for Fibre‑Channel HBAs and high‑speed network adapters.

Redundant hot‑swappable power supplies and fan modules help to minimize unplanned hardware downtime. The embedded Oracle Integrated Lights‑Out Manager (ILOM) service processor delivers comprehensive out‑of‑band remote management, real‑time hardware health monitoring, fault notification and firmware upgrades. Supported operating systems include Oracle Linux, Red Hat Enterprise Linux, SUSE Linux Enterprise Server and Microsoft Windows. Oracle Server X6‑2 serves as a stable, validated infrastructure building block for database deployment, application consolidation and virtualization in on‑premises data centersOracle.

Key hardware bullet points

• Form Factor: 1U Rack‑mount

• CPU: Dual Intel Xeon E5‑2600 v4, up to 22 cores per socket

• Memory: 24 DDR4‑2400 DIMM slots, max 768 GB

• Local Storage: Up to 8 × 2.5‑inch hot‑swap bays (SAS‑3 HDD / SATA‑SSD)

• Expansion: 4 × low‑profile PCIe Gen3 slots

• System Management: Oracle ILOM service processor

• Redundancy: Hot‑swap redundant power supplies & fan modules

• Supported OS: Oracle Linux, RHEL, SUSE Linux, Microsoft Windows
